- Camera
- Image Sensor2 MP CMOS image sensor
- Max. Resolution1920 (H) × 1080 (V)
- Min. IlluminationColor: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter TimePAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s
- Day & NightColor
- Angle AdjustmentPan: 0° to 360°; Tilt: 0° to 180°; Rotate: 0° to 360°
- Slow ShutterMax. 16x
- Lens
- Lens Type3.6 mm, 6 mm fixed lens
- Focal Length & FOV83.6° (3.6 mm), 52.8° (6 mm)
- Lens MountM16
- Image
- Image SettingsBrightness, Sharpness, 3D DNR, Mirror, Smart light
- Frame RatePAL: 1080p@25fps,NTSC: 1080p@30fps
- Wide Dynamic Range (WDR)130 dB
- Image EnhancementWDR, BLC, HLC
- Privacy Mask4 programmable privacy masks
- White BalanceAuto/Manual
- White LightUp to 20 m
- AGCYes
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- Event
- Motion Detection4 programmable areas
- General
- MaterialMetal
- Dimension181.4 mm × 70 mm × 68 mm (7.14" × 2.75" × 2.68")
- Approx. 390 g (0.86 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- CommunicationUp the coax, Protocol: HIKVISION-C (TVI output)
- Power Supply12 VDC ±25%
- ConsumptionMax. 3 W
- IR RangeN/A
