- Up to 16 channel IP cameras can be connected
- Supports decoding H.265+/H.265/H.264+/H.264/MPEG4 video formats
- Up to 4K high-definition live view, storage and playback
- Up to 160 Mbps high incoming bandwidth ensures IP cameras can be connected
- 2 HDMI (different source) and 2 VGA (different source) interfaces
- 8 HDD can be used for continuous video recording
- Compatible with third-party network cameras
- Supports some specialist cameras, including people counting camera/ANPR (automatic number plate recognition) camera
- Advanced streaming technology enables smooth live view in poor network conditions.
- Video And Audio
- IP Video Input16-ch
- HDMI 1 OutputHDMI1: 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,HDMI2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
- HDMI 2 OutputVGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,VGA2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
- VGA OutputHDMI,VGA
- Incoming Bandwidth160 Mbps
- Audio Output2-ch, RCA (Linear, 1 K Ω)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 kΩ)
- General
- Power Supply100 to 240 VAC, 50 to 60 Hz
- Consumption200 W
- Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity10 to 90 %
- Chassis19-inch rack-mounted 2U chassis
- Dimension (W × D × H)445 × 470 × 90 mm (17.5" × 18.5" × 3.5")
- Weight≤ 8 kg (17.6 lb)
- Auxiliary Interface
- SATA8 SATA interfaces
- ESATA1 eSATA interface
- CapacityUp to 6 TB capacity for each HDD
- Serial InterfaceRS-232; RS-485; Keyboard
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
- Alarm In/Out16/4
- RAID
- RAID TypeNo
- PoE
- InterfaceN/A
- Network
- Network ProtocolTCP/IP, DHCP, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Network Interface2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces
- Decoding
- Decoding FormatH.265+,H.265,H.264+,H.264
- Decoding Capability8-ch @ 1080p
- Synchronous Playback16-ch
- Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF /CIF/QCIF
شما میتوانید برای خرید این دستگاه تحت شبکه هایک ویژن با گارانتی پارس ارتباط با فروشگاه هایک ویژن تهران (66765923-66765968-09906500074) تماس حاصل فرمایید.
