• Up to 16 channel IP cameras can be connected
• Supports decoding H.265+/H.265/H.264+/H.264/MPEG4 video formats
• Up to 4K high-definition live view, storage and playback
• Up to 160 Mbps high incoming bandwidth ensures IP cameras can be connected
• 2 HDMI (different source) and 2 VGA (different source) interfaces
• 8 HDD can be used for continuous video recording
• Compatible with third-party network cameras
• Supports some specialist cameras, including people counting camera/ANPR (automatic number plate recognition) camera
• Advanced streaming technology enables smooth live view in poor network conditions.

• Video And Audio
• IP Video Input16-ch
• HDMI 1 OutputHDMI1: 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,HDMI2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
• HDMI 2 OutputVGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,VGA2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
• VGA OutputHDMI,VGA
• Incoming Bandwidth160 Mbps
• Audio Output2-ch, RCA (Linear, 1 K Ω)
• Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 kΩ)

• General
• Power Supply100 to 240 VAC, 50 to 60 Hz
• Consumption200 W
• Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity10 to 90 %
• Chassis19-inch rack-mounted 2U chassis
• Dimension (W × D × H)445 × 470 × 90 mm (17.5" × 18.5" × 3.5")
• Weight≤ 8 kg (17.6 lb)
• Auxiliary Interface
• SATA8 SATA interfaces
• ESATA1 eSATA interface
• CapacityUp to 6 TB capacity for each HDD
• Serial InterfaceRS-232; RS-485; Keyboard
• USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
• Alarm In/Out16/4
• RAID
• RAID TypeNo
• PoE
• InterfaceN/A
• Network
• Network ProtocolTCP/IP, DHCP, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
• Network Interface2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces
• Decoding
• Decoding FormatH.265+,H.265,H.264+,H.264
• Decoding Capability8-ch @ 1080p
• Synchronous Playback16-ch
• Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF /CIF/QCIF
